Specifications

• Engine

  add remove
  • Engine Type:
    Single-Cylinder
  • Engine Stroke:
    4-Stroke
  • Valves:
    4
  • Valves Per Cylinder:
    4
  • Valve Configuration:
    SOHC
  • Bore (in):
    4.13
  • Stroke (in):
    3.15
  • Displacement (cc):
    692.7
  • Horsepower (bhp):
    74
  • Torque (Ft Lbs):
    52.4
• TRANSMISSION

  add remove
  • Transmission Type:
    Manual
  • Number Of Speeds:
    6
  • Primary Drive (Rear Wheel):
    Chain
  • Reverse:
    No
• TECHNICAL SPECIFICATIONS

  add remove
  • Wheelbase (in):
    58.3
  • Ground Clearance (in):
    10.6
  • Dry Weight (lbs):
    319.7
  • Fuel Capacity (gal):
    3.4
  • Engine Displacement to Weight (cc):
    2.17
• SUSPENSION

  add remove
  • Front Suspension Brand Name:
    WP
  • Front Suspension Type:
    Inverted Fork
  • Front Suspension Size (in):
    1.9
  • Front Travel (in):
    8.5
  • Rear Suspension Type:
    Twin Sided Swing Arm
  • Rear Travel (in):
    9.8
  • Number Rear Shock Absorbers:
    1
• WHEELS & TIRES

  add remove
  • Front Tire (Full Spec):
    Continental ContiAttack: 120/70 R17
  • Rear Tire (Full Spec):
    Continental ContiAttack: 160/60 R17
• BRAKES

  add remove
  • Brake Brand Name:
    Brembo®
  • Front Brake Type:
    Disc
  • Front Brake Diameter (in):
    12.6
  • Rear Brake Type:
    Disc
  • Rear Brake Diameter (in):
    9.5
