Specifications

• ENGINE

  add remove
  • Engine Type:
    Parallel Twin
  • Cylinders:
    2
  • Engine Stroke:
    4-Stroke
  • Cooling:
    Liquid
  • Valves:
    8
  • Valves Per Cylinder:
    4
  • Valve Configuration:
    DOHC
  • Bore (in):
    2.92
  • Stroke (in):
    2.29
  • Displacement (cc):
    498
  • Compression Ratio:
    10.2:1
  • Carburetion Brand:
    Keihin
  • Carburetor:
    Yes
  • Number Of Carburetors:
    2
  • Carburetion Type:
    Carburetor
  • Fuel Requirements:
    Regular
  • Turbocharged:
    No
  • Supercharged:
    No
  • Torque (Ft Lbs):
    33
• TRANSMISSION

  add remove
  • Transmission Type:
    Manual
  • Number Of Speeds:
    6
  • Primary Drive (Rear Wheel):
    Chain
  • Reverse:
    No
• TECHNICAL SPECIFICATIONS

  add remove
  • Length (in):
    91.3
  • Width (in):
    32.7
  • Height (in):
    44.3
  • Wheelbase (in):
    62.8
  • Ground Clearance (in):
    4.7
  • Dry Weight (lbs):
    439
  • Fuel Capacity (gal):
    4
  • Engine Displacement to Weight (cc):
    1.13
• SUSPENSION

  add remove
  • Front Suspension Type:
    Telescopic Fork
  • Front Suspension Size (in):
    1.6
  • Front Travel (in):
    5.9
  • Front Adjustable Fork Pre-Load:
    No
  • Front Adjustable Rebound Damping:
    No
  • Front Central Suspension Strut:
    No
  • Rear Suspension Type:
    Twin Sided Swing Arm
  • Rear Travel (in):
    3.9
  • Rear Adjustable Shock / Spring Pre-Load:
    Yes
  • Rear Adjustable Rebound Damping:
    No
  • Number Rear Shock Absorbers:
    2
  • Steering Damper:
    No
  • Air Adjustable:
    No
• WHEELS & TIRES

  add remove
  • Tube / Tubeless:
    Tubed
  • Front Tire (Full Spec):
    100/90 R19
  • Rear Tire (Full Spec):
    140/90 R15
• BRAKES

  add remove
  • Front Brake Type:
    Hydraulic Disc
  • Rear Brake Type:
    Drum
• SEATS

  add remove
  • Seat Type:
    One-Piece
  • Seat Location:
    Driver and Passenger
  • Seat Material:
    Vinyl
  • Seat Height (in):
    28.1
  • Number Of Seats:
    2
