Specifications

• Engine & Transmission

  add remove
  • Engine Type:
    Liquid cooled, inline 3-cylinder,12 valve, DOHC, 240° Firing order
  • Capacity:
    660 cc
  • Bore:
    2.9 in
  • Stroke:
    2.0 in
  • Compression:
    12.05
  • Max Power:
    69.8 kW / 11250 rpm
  • Max Torque:
    50.9 ft-lb / 8250 rpm
  • System:
    Multipoint sequential electronic fuel injection with electronic throttle control
  • Exhaust:
    Stainless steel 3 into 1 header system with low single sided stainless steel silencer
  • Final Drive:
    X-ring chain
  • Clutch:
    Wet, multi-plate, slip and assist
  • Gearbox:
    6-speed
• Chassis

  add remove
  • Frame:
    Tubular steel perimeter frame
  • Swingarm:
    Twin-sided, fabricated steel
  • Front Wheel:
    Cast aluminium alloy 5 spoke, 17 x 3.5 in
  • Rear Wheel:
    Cast aluminium alloy 5 spoke, 17 x 5.5 in
  • Front Tyre:
    120/70 ZR 17
  • Rear Tyre:
    180/55 ZR 17
  • Front Suspension:
    Showa 41mm (1.61in) upside down Separate Function Forks - Big Piston (SFF-BP), 110mm (4.33in) Wheel travel
  • Rear Suspension:
    Showa monoshock RSU, with preload adjustment, 130mm (5.11in) Wheel travel
  • Front Brake:
    Twin 310mm (12.20in) floating discs, 4 piston radial calipers, ABS
  • Rear Brake:
    Single 220mm (8.66in) fixed disc, single piston sliding caliper, ABS
  • Instrument Display and Functions:
    Multi-function instruments with colour TFT screen
• Dimensions & Weights

  add remove
  • Width Handlebars:
    29.0 in
  • Height Without Mirror:
    45.1 in
  • Seat Height:
    31.9 in
  • Wheelbase:
    56.1 in
  • Rake:
    23.8 º
  • Trail:
    3.2 in
  • Tank Capacity:
    3.7 gal
  • Wet Weight:
    443 lbs
