Specifications

• Engine & Transmission

  add remove
  • Engine Type:
    Liquid-cooled, 12 valve, DOHC, inline 3-cylinder
  • Capacity:
    2458 cc
  • Bore:
    4.3 in
  • Stroke:
    3.4 in
  • Compression:
    10.8:1
  • Max Power:
    134 kW / 7000 rpm
  • Max Torque:
    166.0 ft-lb / 4000 rpm
  • System:
    Multipoint sequential electronic fuel injection with electronic throttle control
  • Exhaust:
    Stainless steel 3 into 1 header system with 3 exit silencer
  • Final Drive:
    Shaft Drive
  • Clutch:
    Wet, multi-plate hydraulically operated, torque assist
  • Gearbox:
    6 speed
• Chassis

  add remove
  • Frame:
    Full aluminium frame
  • Swingarm:
    Single-sided, cast aluminium
  • Front Wheel:
    17 x 3.5" cast aluminium
  • Rear Wheel:
    16 x 7.5" cast aluminium
  • Front Tyre:
    150/80 R17 V
  • Rear Tyre:
    240/50 R16 V
  • Front Suspension:
    Showa 47mm USD 1 1 cartridge front forks, compression and rebound damping adjustment, 120mm wheel travel.
  • Rear Suspension:
    Fully adjustable Showa piggyback reservoir RSU with remote hydraulic preload adjuster, 107mm wheel travel.
  • Front Brake:
    Twin 320mm discs, Brembo M4.32 Stylema® 4-piston monobloc caliper, Optimised Cornering-ABS
  • Rear Brake:
    Single 300mm disc, Brembo M4.32 4-piston monobloc caliper, Optimised Cornering-ABS
  • Instrument Display and Functions:
    Multi-function instruments with colour TFT screen
• Dimensions & Weights

  add remove
  • Width Handlebars:
    36.2 in
  • Height Without Mirror:
    46.6 in
  • Seat Height:
    29.5 in
  • Wheelbase:
    66.0 in
  • Rake:
    27.9 º
  • Trail:
    5.3 in
  • Tank Capacity:
    4.8 gal
  • Wet Weight:
    320 kg
• Fuel Consumption

  add remove
  • Fuel Consumption:
    (6.6 litres/100km) 42.8 mpg
  • CO₂ Figures:
    EURO 5 CO2 emissions and fuel consumption data are measured according to regulation 168/2013/EC. Figures for fuel consumption are derived from specific test conditions and are for comparative purposes only. They may not reflect real driving results. 152 g
