Specifications

• Engine & Transmission

  add remove
  • Engine Type:
    Liquid-cooled, 12 valve, DOHC, inline 3-cylinder
  • Capacity:
    1160 cc
  • Bore:
    3.5 in
  • Stroke:
    2.4 in
  • Compression:
    13.2:1
  • Max Torque:
    92.2 ft-lb
  • System:
    Multipoint sequential electronic fuel injection with electronic throttle control
  • Exhaust:
    Multipoint sequential electronic fuel injection with electronic throttle control
  • Final Drive:
    X-ring chain
  • Clutch:
    Wet, multi-plate, slip & assist
  • Gearbox:
    6 speed
• Chassis

  add remove
  • Frame:
    Aluminium twin spar frame, bolt-on aluminium rear subframe
  • Swingarm:
    Aluminium, single-sided
  • Front Wheel:
    Cast aluminium, 17 x 3.50 in
  • Rear Wheel:
    Cast aluminium, 17 x 6.00 in
  • Front Tyre:
    Metzeler Racetec RR K3 120/70 ZR17
  • Rear Tyre:
    Metzeler Racetec RR K3 190/55 ZR17
  • Front Suspension:
    Öhlins 43 mm NIX30 upside down forks with adjustable preload, rebound and compression damping, 120 mm travel.
  • Rear Suspension:
    Öhlins TTX36 twin tube monoshock with preload, rebound and compression damping, 120 mm rear wheel travel.
  • Front Brake:
    Twin 320mm floating discs. Brembo Stylema monobloc calipers, OC-ABS, radial master cylinder with separate reservoir, span & ratio adjustable.
  • Rear Brake:
    Single 220mm disc. Brembo twin piston caliper, OC-ABS. Rear master cylinder with separate reservoir.
• Dimensions & Weights

  add remove
  • Width Handlebars:
    31.2 in
  • Height Without Mirror:
    42.9 in
  • Seat Height:
    32.7 in
  • Wheelbase:
    56.9 in
  • Rake:
    23.9 °
  • Trail:
    4.1 in
  • Tank Capacity:
    4.1 gal
