Specifications

• Engine & Transmission

  add remove
  • Engine Type:
    Liquid-cooled parallel twin, 8 valve, SOHC, 270° firing order
  • Capacity:
    1200 cc
  • Bore:
    3.8 in
  • Stroke:
    3.1 in
  • Compression:
    10.0:1
  • Max Power:
    57.5 kW / 6000 rpm
  • Max Torque:
    78.2 ft-lb / 3750 rpm
  • System:
    Electronic fuel injection with electronic throttle control. 3 rider modes (Road, Rain, Sport)
  • Exhaust:
    Brushed stainless steel 2 into 2 exhaust system with twin Akrapovič silencers and carbon tips
  • Final Drive:
    X-ring chain
  • Clutch:
    Wet, multi-plate, slip
  • Gearbox:
    6-speed
• Chassis

  add remove
  • Frame:
    Tubular steel cradle
  • Swingarm:
    Twin-sided tubular steel
  • Front Wheel:
    32-spoke 19 x 2.5 inches
  • Rear Wheel:
    32-spoke 16 x 3.5 inches
  • Front Tyre:
    100/90-19
  • Rear Tyre:
    150/80-16
  • Front Suspension:
    43mm Öhlins NIX 30 upside-down forks, adjustable for pre-load, compression and rebound damping. 90 mm wheel travel.
  • Rear Suspension:
    Öhlins monoshock with linkage, adjustable for pre-load and rebound damping. 77 mm wheel travel
  • Front Brake:
    Twin 310mm fixed discs, Brembo M50 4-piston radial calipers, ABS
  • Rear Brake:
    Single 255mm fixed disc, Nissin axial caliper, ABS
  • Instrument Display and Functions:
    Analogue speedometer with integrated multi-function LCD display and TFC branding
• Dimensions & Weights

  add remove
  • Width Handlebars:
    30.5 in
  • Height Without Mirror:
    41.7 in
  • Seat Height:
    690 - 700 mm
  • Wheelbase:
    59.4 in
  • Rake:
    25.7 º
  • Trail:
    3.7 in
  • Tank Capacity:
    2.4 gal
  • Wet Weight:
    237 kg
• Fuel Consumption

  add remove
  • CO₂ Figures:
    105 g/km EURO 5 plus CO2 emissions and fuel consumption data are measured according to regulation 168/2013/EC. Figures for fuel consumption are derived from specific test conditions and are for comparative purposes only. They may not reflect real driving
