Specifications

• ENGINE

  add remove
  • Rated output:
    109 hp at 7,250 rpm
  • Engine:
    Standard
  • Engine Type:
    Flat Twin
  • Cylinders:
    2
  • Engine Stroke:
    4-Stroke
  • Horsepower (bhp):
    109
  • Horsepower (kW):
    81.3
  • Horsepower RPM:
    7250
  • Torque (Ft Lbs):
    85.5
  • Torque (Nm):
    115.9
  • Torque RPM:
    6000
  • Cooling:
    Air / Oil
  • Valves:
    8
  • Valves Per Cylinder:
    4
  • Valve Configuration:
    DOHC
  • Bore (mm):
    101
  • Bore (in):
    4
  • Stroke (mm):
    73
  • Stroke (in):
    2.9
  • Displacement (cc):
    1170
  • Displacement (ci):
    71.4
  • Turbocharged:
    No
  • Supercharged:
    No
  • Starter:
    Electric
  • Fuel Type:
    Gas
  • Fuel Requirements:
    Premium
  • Carburetion:
    Standard
  • Fuel Injector:
    Yes
  • Carburetor:
    No
  • Carburetion Type:
    Fuel Injected
  • Parental Controls:
    Not Available
  • Fuel Injector Size (mm):
    50
  • Other Engine:
    Optional
  • Type:
    Air / oil-cooled two-cylinder, four-stroke boxer engine with two camshafts and four radially-arranged valves per cylinder as well as central counterbalance shaft
  • Displacement:
    4.0” x 2.9”
  • Capacity:
    1,170 cc
  • Max. torque:
    85.5 lbs-ft. at 6,000 rpm
  • Compression ratio:
    12.0:1
  • Mixture control:
    Electronic port fuel injection
  • Emission control:
    Closed-loop 3-way catalytic converter
• PERFORMANCE / FUEL CONSUMPTION

  add remove
  • Maximum speed:
    over 124 mph
• POWER TRANSMISSION

  add remove
  • Clutch:
    Single dry plate clutch, hydraulically operated
  • Gearbox:
    Claw-shifted six-speed transmission with helical-cut splines
  • Drive:
    Shaft drive
• CHASSIS / SUSPENSION / BRAKES

  add remove
  • Frame:
    Four-part frame concept with front frame and three-part rear frame, load-bearing engine-gearbox unit, rear-seat frame removeable for one-up riding
  • Suspension travel, front / rear:
    4.7" / 4.7"
  • Front wheel location / suspension:
    Upside-down telescopic forks, 46 mm fixed-fork-tube diameter
  • Rear wheel location / suspension:
    Cast aluminum single swing arm with BMW Motorrad Paralever; central spring strut, spring preload fully adjustable by handwheel, adjustable rebound-stage damping
  • Wheelbase:
    58.5” mm
  • Castor:
    4.3"
  • Steering head angle:
    63.2°
  • Wheels:
    Spoke wheels
  • Rim, front:
    3.50 x 17"
  • Rim, rear:
    5.50 x 17"
  • Tyre, front:
    120 / 70 ZR 17
  • Tyre, rear:
    5.50 x 17"
  • Brake, front:
    Twin-disc brakes, diameter 12.6", 4-piston calipers
  • Brake, rear:
    Single disc brake, diameter 10.4", double-piston floating caliper
  • ABS:
    BMW Motorrad ABS Pro
• DIMENSIONS / WEIGHTS

  add remove
  • Usable tank volume:
    4.5 gal. l
  • Reserve:
    app. 0.8 gal. l
  • Length:
    82.9” mm
  • Seat height, unladen:
    31.7”
  • Inner leg curve at unladen weight:
    70.3”
• EQUIPMENT

  add remove
  • Standard equipment:
    LED headlight and turn signals
    Dual speed indicator and rational-speed sensor instrument with on-board computer content
    Automatic Stability Control (ASC)
    Ride Modes: Rain & Road
    Drivetrain and final drive black
    Upside down front fork fully
  • Optional equipment:
    Ride Modes PRO (incl. Ride Mode: Dynamic)
    Cruise control and heated grips
    Aluminum Fuel Tank
    Paint sets
    Option 719 wheel Classic / Sport
    Option 719 billet packages I & II
  • Optional accessories:
    Tail short
    Tail Tracker
    Function integrated turning signals
    Cylinder head covers 2V-Style
• TRANSMISSION

  add remove
  • Transmission:
    Standard
  • Transmission Type:
    Manual
  • Number Of Speeds:
    6
  • Overdrive:
    Yes
  • Primary Drive (Rear Wheel):
    Shaft
  • Gear Ratio (1):
    2.38
  • Gear Ratio (2):
    1.7
  • Gear Ratio (3):
    1.3
  • Gear Ratio (4):
    1.07
  • Gear Ratio (5):
    0.94
  • Gear Ratio (6):
    0.85
  • Reverse:
    No
  • Final Drive Ratio:
    2.91
  • Heel Toe Shifter:
    Not Available
  • Adjustable Throttle:
    Not Available
  • Other Transmission:
    Not Available
• TECHNICAL SPECIFICATIONS

  add remove
  • Dimensions:
    Standard
  • Length (in):
    82.9
  • Length (mm):
    2105.7
  • Width (in):
    34.8
  • Width (mm):
    883.9
  • Wheelbase (in):
    58.5
  • Wheelbase (mm):
    1487
  • Weight:
    Standard
  • Wet Weight (lbs):
    487
  • Wet Weight (kg):
    220.9
  • GVWR (lbs):
    948
  • GVWR (kgs):
    430
  • Capacities:
    Standard
  • Fuel Capacity (gal):
    4.5
  • Fuel Capacity (l):
    17
  • Fuel Capacity Reserve (gal):
    0.8
  • Fuel Capacity Reserve (l):
    3
  • Performance:
    Standard
  • Engine Displacement to Weight (cc):
    2.4
  • Payload Capacity (lbs):
    460
  • Payload Capacity (kgs):
    208.7
  • Height (in):
    48.8
  • Height (mm):
    1240
• EXTERIOR

  add remove
  • Construction:
    Standard
  • Frame:
    Steel
  • Body Material:
    Plastic
  • Floor Boards:
    Not Available
  • Foot Pegs:
    Standard
  • Foot Peg Location:
    Driver and Passenger
  • Hand Grips:
    Standard
  • Handlebars:
    Standard
  • Handlebar Pads:
    Not Available
  • Exterior Guards:
    Standard
  • Belt Guard:
    No
  • Brush Guard:
    No
  • Chain Guard:
    No
  • Fork Guards:
    No
  • Hand Guards:
    No
  • Light Guard:
    No
  • Exterior Covers:
    Standard
  • Front Fender:
    Standard
  • Front Fender Trim:
    Not Available
  • Front Fender Rail:
    Not Available
  • Rear Fender:
    Standard
  • Rear Fender Trim:
    Not Available
  • Rear Fender Rail:
    Not Available
  • Tank Divider:
    Not Available
  • Stand:
    Standard
  • Stand Type:
    Kick
  • Upper Fairing:
    Not Available
  • Lower Fairing:
    Not Available
  • Spoiler:
    Not Available
  • Skid Plate:
    Not Available
  • Wind Deflector:
    Not Available
  • License Plate:
    Standard
  • Other Exterior:
    Not Available
  • Top Crown:
    Standard
  • Radiator Cover:
    No
  • Tank Guard:
    No
• SUSPENSION

  add remove
  • Front Suspension:
    Standard
  • Front Suspension Type:
    Inverted Fork
  • Front Travel (in):
    4.7
  • Front Travel (mm):
    120
  • Front Central Suspension Strut:
    No
  • Steering Damper:
    Yes
  • Rear Suspension:
    Standard
  • Rear Suspension Brand Name:
    Paralever
  • Rear Suspension Type:
    Single Sided Swing Arm
  • Rear Travel (in):
    4.7
  • Rear Travel (mm):
    120
  • Rear Adjustable Shock / Spring Pre-Load:
    Yes
  • Rear Adjustable Rebound Damping:
    Yes
  • Number Rear Shock Absorbers:
    1
  • Air Adjustable:
    No
  • Other Suspension:
    Not Available
  • Rear Suspension Material:
    Aluminum
  • Front Suspension Size (in):
    1.8
  • Front Suspension Size (mm):
    46
• WHEELS & TIRES

  add remove
  • Wheels:
    Standard
  • Wheels Composition:
    Steel
  • Tube / Tubeless:
    Tubed
  • Front Wheel Width (in):
    3.5
  • Rear Wheel Width (in):
    5.5
  • Tires:
    Standard
  • Front Tire Width:
    120
  • Front Tire Aspect Ratio:
    70
  • Front Tire Speed Rating:
    V
  • Front Wheel Diameter:
    17
  • Rear Tire Width:
    180
  • Rear Tire Aspect Ratio:
    55
  • Rear Tire Speed Rating:
    V
  • Rear Wheel Diameter:
    17
  • Front Tire (Full Spec):
    120/70 ZR17 58V
  • Rear Tire (Full Spec):
    180/55 ZR17 73V
  • Spare Tire:
    Not Available
  • Other Wheels & Tires:
    Not Available
• BRAKES

  add remove
  • Brakes:
    Standard
  • Front Brake Type:
    Dual Hydraulic Disc
  • Front Brake Diameter (in):
    12.6
  • Front Brake Diameter (mm):
    320
  • Rear Brake Type:
    Hydraulic Disc
  • Rear Brake Diameter (in):
    10.4
  • Rear Brake Diameter (mm):
    265
  • Anti-Lock Brakes:
    Standard
  • Linked Brake System Front to Rear:
    Standard
  • Regenerative Braking:
    Not Available
  • Regenerative Deceleration:
    Not Available
  • Other Brakes:
    Optional
• AUDIO & COMMUNICATION

  add remove
  • Radio:
    Not Available
  • Speakers:
    Not Available
  • Cassette Player:
    Not Available
  • CD Player:
    Not Available
  • CB Radio:
    Not Available
  • Intercom:
    Not Available
  • Headset:
    Not Available
  • Satellite:
    No
  • Other Audio & Communication:
    Not Available
