Specifications

• ENGINE

  add remove
  • Engine Type:
    In-Line
  • Cylinders:
    4
  • Engine Stroke:
    4-Stroke
  • Cooling:
    Liquid
  • Valves:
    16
  • Valves Per Cylinder:
    4
  • Valve Configuration:
    DOHC
  • Bore (in):
    2.89
  • Stroke (in):
    2.2
  • Displacement (cc):
    948
  • Compression Ratio:
    10.8:1
  • Carburetion Brand:
    Keihin
  • Carburetor:
    No
  • Carburetion Type:
    Fuel Injected
  • Turbocharged:
    No
  • Supercharged:
    No
  • Torque (Ft Lbs):
    72.3
  • Horsepower (bhp):
    111
• TRANSMISSION

  add remove
  • Transmission Type:
    Manual
  • Number Of Speeds:
    6
  • Primary Drive (Rear Wheel):
    Chain
  • Reverse:
    No
• TECHNICAL SPECIFICATIONS

  add remove
  • Length (in):
    83.1
  • Width (in):
    34.1
  • Height (in):
    46.5
  • Wheelbase (in):
    57.9
  • Ground Clearance (in):
    5.1
  • Wet Weight (lbs):
    474.1
  • Fuel Capacity (gal):
    4.5
• SUSPENSION

  add remove
  • Front Suspension Type:
    Inverted Fork
  • Front Suspension Size (in):
    1.6
  • Front Travel (in):
    4.7
  • Front Adjustable Fork Pre-Load:
    Yes
  • Front Adjustable Rebound Damping:
    Yes
  • Front Central Suspension Strut:
    No
  • Rear Suspension Type:
    Twin Sided Swing Arm
  • Rear Travel (in):
    5.5
  • Rear Adjustable Shock / Spring Pre-Load:
    Yes
  • Rear Adjustable Rebound Damping:
    Yes
  • Number Rear Shock Absorbers:
    1
  • Rear Suspension Material:
    Aluminum
  • Steering Damper:
    No
  • Air Adjustable:
    No
• WHEELS & TIRES

  add remove
  • Front Tire (Full Spec):
    Dunlop® GPR-300F: 120/70-ZR17M/C 58W
  • Rear Tire (Full Spec):
    Dunlop® GPR-300: 180/55-ZR17M/C 73W
• BRAKES

  add remove
  • Front Brake Type:
    Dual Hydraulic Disc
  • Front Brake Diameter (in):
    11.8
  • Rear Brake Type:
    Hydraulic Disc
  • Rear Brake Diameter (in):
    9.8
• SEATS

  add remove
  • Seat Type:
    One-Piece
  • Seat Location:
    Driver and Passenger
  • Seat Material:
    Vinyl
  • Seat Height (in):
    32.9
  • Number Of Seats:
    2
