Specifications

• ENGINE

  add remove
  • Engine:
    Standard
  • Engine Type:
    Flat Twin
  • Cylinders:
    2
  • Engine Stroke:
    4-Stroke
  • Horsepower (bhp):
    136
  • Horsepower (kW):
    100
  • Horsepower RPM:
    7750
  • Torque (Ft Lbs):
    105
  • Torque (Nm):
    143
  • Torque RPM:
    6250
  • Cooling:
    Liquid / Air
  • Valves:
    8
  • Valves Per Cylinder:
    4
  • Valve Configuration:
    DOHC
  • Bore (mm):
    102.5
  • Bore (in):
    4.04
  • Stroke (mm):
    76
  • Stroke (in):
    2.99
  • Displacement (cc):
    1254
  • Displacement (ci):
    76.5
  • Turbocharged:
    No
  • Supercharged:
    No
  • Starter:
    Electric
  • Fuel Type:
    Gas
  • Fuel Requirements:
    Premium
  • Carburetion:
    Standard
  • Fuel Injector:
    Yes
  • Carburetor:
    No
  • Carburetion Type:
    Fuel Injected
  • Parental Controls:
    Not Available
  • US Miles Per Gallon (Hwy):
    50
  • Fuel Injector Size (mm):
    52
  • Other Engine:
    Optional
  • Type:
    Air/liquid-cooled four stroke flat twin engine, double overhead camshaft, one balance shaft and variable engine timing system BMW ShiftCam.
  • Bore / stroke:
    102,5 mm x 76 mm
  • Capacity:
    1.254 ccm
  • Rated output:
    100 kW at 7,750 rpm
  • Max. torque:
    143 Nm at 6,250 rpm
  • Compression ratio:
    12.5:1
  • Mixture control:
    Electronic intake pipe injection
  • Emission control:
    Closed-loop 3-way catalytic converter, emission standard EU-4
• PERFORMANCE / FUEL CONSUMPTION

  add remove
  • Maximum speed:
    Over 200 km/h
  • Fuel consumption per 100 km based on WMTC:
    4.75 l/100km
  • CO₂ emission based on WMTC:
    110 g/km
  • Fuel type:
    Unleaded super, octane number 95 (RON), adapive fuel quality regulation (91 to 98 RON)
• POWER TRANSMISSION

  add remove
  • Clutch:
    Oil lubricated clutch, hydraulically operated
  • Gearbox:
    Constant mesh 6-speed gearbox with helical gear teeth
  • Drive:
    Shaft drive
• CHASSIS / SUSPENSION / BRAKES

  add remove
  • Frame:
    Two-section frame, front- and bolted on rear frame, load-bearing engine
  • Front suspension / spring elements:
    BMW Motorrad Telelever; stanchion diameter 37 mm, central spring strut
  • Suspension travel, front / rear:
    120 mm / 136 mm
  • Rear wheel location / suspension:
    Cast aluminium single-sided swing arm with BMW Motorrad Paralever; WAD strut (travel-related damping), spring pre-load hydraulically adjustable (continuously variable) at handwheel, rebound damping adjustable at handwheel
  • Wheelbase:
    0.1 in
  • Castor:
    116
  • Steering head angle:
    64,1°
  • Wheels:
    Cast aluminium wheels
  • Rim, front:
    3,50'' x 17''
  • Rim, rear:
    5,50'' x 17''
  • Tyre, front:
    120/70 ZR 17
  • Tyre, rear:
    180/55 ZR 17
  • Brake, front:
    Dual disc brake, floating brake discs, diameter 320 mm, 4-piston radial calipers
  • Brake, rear:
    Single disc brake, diameter 276 mm, double-piston floating caliper
  • ABS:
    BMW Motorrad Integral ABS (part-integral)
• DIMENSIONS / WEIGHTS

  add remove
  • Inner leg curve:
    1,810 / 1,850 mm (OE low seat: 1,740 / 1,780 mm; OE high seat: 1,875 / 1,915)
  • Usable tank volume:
    Approx. 25 l
  • Reserve:
    Approx. 4 l
  • Unladen weight, road ready, fully fuelled:
    279
  • Max. permitted weight:
    1,113 lbs
  • Payload (with standard equipment):
    498 lbs
  • Length (including mud guard):
    2.222 mm
  • Seat height:
    05 / 825 mm (OE low seat: 760 / 780 mm; OE high seat: 830 / 850 mm)
  • Height (including windshield):
    Min. 1,405 mm; max. 1,570 mm (Style Sport: min. 1,360 mm; max. 1,480 mm)
  • Width (including mirrors):
    985 mm
  • Width (including suitcase):
    990 mm
• TRANSMISSION

  add remove
  • Transmission:
    Standard
  • Transmission Type:
    Manual
  • Number Of Speeds:
    6
  • Overdrive:
    Yes
  • Primary Drive (Rear Wheel):
    Shaft
  • Gear Ratio (1):
    2.44
  • Gear Ratio (2):
    1.71
  • Gear Ratio (3):
    1.3
  • Gear Ratio (4):
    1.06
  • Gear Ratio (5):
    0.94
  • Gear Ratio (6):
    0.85
  • Reverse:
    No
  • Final Drive Ratio:
    2.75
  • Heel Toe Shifter:
    Not Available
  • Adjustable Throttle:
    Not Available
  • Other Transmission:
    Optional
• TECHNICAL SPECIFICATIONS

  add remove
  • Dimensions:
    Standard
  • Length (in):
    87.5
  • Length (mm):
    2222
  • Width (in):
    38.8
  • Width (mm):
    985
  • Wheelbase (in):
    58.5
  • Wheelbase (mm):
    1485
  • Weight:
    Standard
  • Wet Weight (lbs):
    615
  • Wet Weight (kg):
    279
  • GVWR (lbs):
    1113
  • GVWR (kgs):
    505
  • Capacities:
    Standard
  • Fuel Capacity (gal):
    6.6
  • Fuel Capacity (l):
    25
  • Fuel Capacity Reserve (gal):
    1
  • Fuel Capacity Reserve (l):
    4
  • Performance:
    Standard
  • Payload Capacity (lbs):
    498
  • Payload Capacity (kgs):
    226
  • Height (in):
    55.3
  • Height (mm):
    1405
• EXTERIOR

  add remove
  • Construction:
    Standard
  • Frame:
    Aluminum / Steel
  • Body Material:
    Plastic
  • Floor Boards:
    Not Available
  • Foot Pegs:
    Standard
  • Foot Peg Location:
    Driver and Passenger
  • Hand Grips:
    Standard
  • Handlebars:
    Standard
  • Handlebar Pads:
    Not Available
  • Exterior Guards:
    Standard
  • Belt Guard:
    No
  • Brush Guard:
    No
  • Chain Guard:
    No
  • Fork Guards:
    Yes
  • Light Guard:
    No
  • Exterior Covers:
    Standard
  • Front Fender:
    Standard
  • Front Fender Trim:
    Not Available
  • Front Fender Rail:
    Not Available
  • Rear Fender:
    Standard
  • Rear Fender Trim:
    Not Available
  • Rear Fender Rail:
    Not Available
  • Tank Divider:
    Not Available
  • Stand:
    Standard
  • Stand Type:
    Center / Kick
  • Upper Fairing:
    Standard
  • Lower Fairing:
    Standard
  • Spoiler:
    Not Available
  • Skid Plate:
    Not Available
  • Wind Deflector:
    Standard
  • License Plate:
    Standard
  • Other Exterior:
    Not Available
  • Top Crown:
    Standard
  • Radiator Cover:
    No
  • Tank Guard:
    No
• SUSPENSION

  add remove
  • Front Suspension:
    Standard
  • Front Suspension Brand Name:
    Telelever
  • Front Suspension Type:
    Telescopic Fork
  • Front Travel (in):
    4.7
  • Front Travel (mm):
    120
  • Front Adjustable Fork Pre-Load:
    Yes
  • Front Adjustable Rebound Damping:
    Yes
  • Front Central Suspension Strut:
    Yes
  • Steering Damper:
    Yes
  • Rear Suspension:
    Standard
  • Rear Suspension Brand Name:
    Paralever
  • Rear Suspension Type:
    Single Sided Swing Arm
  • Rear Travel (in):
    5.4
  • Rear Travel (mm):
    136
  • Rear Adjustable Shock / Spring Pre-Load:
    Yes
  • Rear Adjustable Rebound Damping:
    Yes
  • Number Rear Shock Absorbers:
    1
  • Air Adjustable:
    No
  • Other Suspension:
    Not Available
  • Rear Suspension Material:
    Aluminum
  • Front Suspension Size (in):
    1.5
  • Front Suspension Size (mm):
    37
• WHEELS & TIRES

  add remove
  • Wheels:
    Standard
  • Wheels Composition:
    Aluminum
  • Tube / Tubeless:
    Tubeless
  • Front Wheel Width (in):
    3.5
  • Rear Wheel Width (in):
    5.5
  • Tires:
    Standard
  • Front Tire Width:
    120
  • Front Tire Aspect Ratio:
    70
  • Front Tire Speed Rating:
    Z
  • Front Wheel Diameter:
    17
  • Rear Tire Width:
    180
  • Rear Tire Aspect Ratio:
    55
  • Rear Tire Speed Rating:
    Z
  • Rear Wheel Diameter:
    17
  • Front Tire (Full Spec):
    120/70 ZR17
  • Rear Tire (Full Spec):
    180/55 ZR17
  • Spare Tire:
    Not Available
  • Other Wheels & Tires:
    Optional
  • Chromed:
    No
• BRAKES

  add remove
  • Brakes:
    Standard
  • Front Brake Type:
    Dual Hydraulic Disc
  • Front Brake Diameter (in):
    12.6
  • Front Brake Diameter (mm):
    320
  • Rear Brake Type:
    Hydraulic Disc
  • Rear Brake Diameter (in):
    10.9
  • Rear Brake Diameter (mm):
    276
  • Anti-Lock Brakes:
    Standard
  • Linked Brake System Front to Rear:
    Standard
  • Regenerative Braking:
    Not Available
  • Regenerative Deceleration:
    Not Available
  • Other Brakes:
    Not Available
• AUDIO & COMMUNICATION

  add remove
  • Radio:
    Optional
  • Speakers:
    Optional
  • Cassette Player:
    Not Available
  • CD Player:
    Optional
  • CB Radio:
    Not Available
  • Intercom:
    Not Available
  • Headset:
    Not Available
  • Other Audio & Communication:
    Not Available
• COMMENTS

  add remove
  • Comment:
    Standard
  • Previous Model Year Accessories:
    Yes
