Specifications

• ENGINE

  add remove
  • Engine Type:
    Single-Cylinder
  • Engine Stroke:
    2-Stroke
  • Bore (in):
    2.83
  • Stroke (in):
    2.83
  • Displacement (cc):
    293.2
• TRANSMISSION

  add remove
  • Transmission:
    Standard
  • Transmission Type:
    Manual
  • Primary Drive (Rear Wheel):
    Chain
  • Number Of Speeds:
    6
  • Final Drive Ratio:
    3.85
  • Overdrive:
    Yes
• TECHNICAL SPECIFICATIONS

  add remove
  • Wheelbase (in):
    58.8
  • Ground Clearance (in):
    13.9
  • Ground Clearance (mm):
    354
  • Dry Weight (lbs):
    224.4
  • Fuel Capacity (gal):
    2.4
  • Fuel Capacity (l):
    9
  • Engine Displacement to Weight (cc):
    1.3
• SUSPENSION

  add remove
  • Front Suspension Type:
    Inverted Fork
  • Front Suspension Size (in):
    1.9
  • Front Travel (in):
    11.8
  • Rear Suspension Type:
    Twin Sided Swing Arm
  • Rear Travel (in):
    11.8
  • Number Rear Shock Absorbers:
    1
  • Front Suspension Brand Name:
    WP XACT
  • Rear Suspension Brand Name:
    WP XACT
• WHEELS & TIRES

  add remove
  • Front Wheel Width (in):
    1.6
  • Rear Wheel Width (in):
    2.15
  • Front Tire Width:
    80
  • Front Wheel Diameter:
    21
  • Rear Wheel Diameter:
    18
  • Front Tire (Full Spec):
    Dunlop® GEOMAX MX-33F 80/100 R21 51M
  • Rear Tire (Full Spec):
    Dunlop® GEOMAX AT81 110/100 R18 64M
  • Rear Tire Width:
    110
  • Front Tire Aspect Ratio:
    100
  • Rear Tire Aspect Ratio:
    100
  • Front Tire Speed Rating:
    M
  • Rear Tire Speed Rating:
    M
• BRAKES

  add remove
  • Front Brake Type:
    Hydraulic Disc
  • Front Brake Diameter (in):
    10.2
  • Rear Brake Type:
    Hydraulic Disc
  • Rear Brake Diameter (in):
    8.7
