Specifications

• ENGINE

  add remove
  • Cylinders:
    3
  • Engine Stroke:
    4-Stroke
  • Horsepower (bhp):
    105
  • Torque (Ft Lbs):
    96
  • Torque RPM:
    5000
  • Bore (mm):
    84
  • Stroke (mm):
    80
  • Displacement (cc):
    1330
  • Compression Ratio:
    12.2:1
• TRANSMISSION

  add remove
  • Transmission Type:
    Manual / Automatic Clutch
  • Number Of Speeds:
    6
  • Primary Drive (Rear Wheel):
    Belt
  • Reverse:
    Yes
  • Gear Ratio (1):
    2.47
  • Gear Ratio (2):
    1.88
  • Gear Ratio (3):
    1.52
  • Gear Ratio (4):
    1.27
  • Gear Ratio (5):
    1.07
  • Gear Ratio (6):
    0.91
• TECHNICAL SPECIFICATIONS

  add remove
  • Length (in):
    104
  • Width (in):
    58.9
  • Height (in):
    43.3
  • Wheelbase (in):
    67.3
  • Ground Clearance (in):
    4.5
  • Dry Weight (lbs):
    899
  • Payload Capacity (lbs):
    439
  • GVWR (lbs):
    1338
  • Fuel Capacity (gal):
    7.1
  • Storage Capacity (cuft):
    1
  • Storage Capacity (l):
    24.4
• SUSPENSION

  add remove
  • Front Suspension Type:
    Independent Double A-Arm
  • Front Travel (in):
    5.1
  • Rear Suspension Type:
    Twin Sided Swing Arm
  • Rear Travel (in):
    5.2
  • Number Rear Shock Absorbers:
    1
  • Front Suspension Brand Name:
    Sachs
  • Rear Suspension Brand Name:
    Sachs
• WHEELS & TIRES

  add remove
  • Front Tire Width:
    165
  • Front Tire Aspect Ratio:
    55
  • Front Wheel Diameter:
    15
  • Rear Tire Width:
    225
  • Rear Tire Aspect Ratio:
    50
  • Rear Wheel Diameter:
    15
  • Front Tire (Full Spec):
    MC 165/55 R15 55H
  • Rear Tire (Full Spec):
    MC 225/50 R15 76H
• BRAKES

  add remove
  • Front Brake Type:
    Dual Hydraulic Disc
  • Front Brake Diameter (in):
    10.6
  • Rear Brake Type:
    Hydraulic Disc
  • Rear Brake Diameter (in):
    10.6
