Specifications

• ENGINE

  add remove
  • Engine Type:
    Parallel Twin
  • Cylinders:
    2
  • Engine Stroke:
    4-Stroke
  • Cooling:
    Liquid
  • Valves:
    8
  • Valves Per Cylinder:
    4
  • Valve Configuration:
    DOHC
  • Bore (in):
    3.15
  • Stroke (in):
    2.7
  • Displacement (cc):
    689
  • Fuel Injector:
    Yes
  • Carburetor:
    No
  • Carburetion Type:
    Fuel Injected
  • Turbocharged:
    No
  • Supercharged:
    No
  • Torque (Ft Lbs):
    50
  • US Miles Per Gallon (Combined):
    58
  • Compression ratio:
    11.5:1
• TRANSMISSION

  add remove
  • Transmission Type:
    Manual
  • Number Of Speeds:
    6
  • Overdrive:
    No
  • Primary Drive (Rear Wheel):
    Chain
  • Gear Ratio (1):
    2.85
  • Gear Ratio (2):
    2.13
  • Gear Ratio (3):
    1.63
  • Gear Ratio (4):
    1.3
  • Gear Ratio (5):
    1.09
  • Gear Ratio (6):
    0.96
  • Reverse:
    No
• TECHNICAL SPECIFICATIONS

  add remove
  • Length (in):
    81.7
  • Width (in):
    32.3
  • Height (in):
    44.5
  • Wheelbase (in):
    55.3
  • Ground Clearance (in):
    5.5
  • Fuel Capacity (gal):
    3.7
  • Engine Displacement to Weight (cc):
    1.68
  • Wet Weight (lbs):
    410
• SUSPENSION

  add remove
  • Front Suspension Type:
    Telescopic Fork
  • Front Suspension Size (in):
    1.6
  • Front Travel (in):
    5.1
  • Front Adjustable Fork Pre-Load:
    No
  • Front Adjustable Rebound Damping:
    No
  • Front Central Suspension Strut:
    No
  • Steering Damper:
    No
  • Rear Suspension Type:
    Twin Sided Swing Arm
  • Rear Travel (in):
    5.1
  • Rear Adjustable Shock / Spring Pre-Load:
    Yes
  • Rear Adjustable Rebound Damping:
    No
  • Number Rear Shock Absorbers:
    1
  • Rear Suspension Material:
    Aluminum
  • Air Adjustable:
    No
• WHEELS & TIRES

  add remove
  • Wheels Composition:
    Aluminum
  • Tube / Tubeless:
    Tubeless
  • Tires:
    Standard
  • Tire Brand:
    Michelin®
  • Front Tire (Full Spec):
    Michelin® Road 5 120/70 ZR17
  • Front Wheel Width (in):
    3.5
• BRAKES

  add remove
  • Front Brake Type:
    Dual Hydraulic Disc
  • Front Brake Diameter (in):
    11.1
  • Rear Brake Type:
    Hydraulic Disc
  • Rear Brake Diameter (in):
    9.6
  • Regenerative Braking:
    Not Available
  • Regenerative Deceleration:
    Not Available
• SEATS

  add remove
  • Seat Type:
    One-Piece
  • Seat Location:
    Driver and Passenger
  • Seat Material:
    Vinyl
  • Seat Specifications:
    Standard
  • Seat Height (in):
    32.9
  • Number Of Seats:
    2
  • Detachable Passenger Seat:
    Not Available
  • Seat Backrest:
    Not Available
  • Grab Rail or Strap:
    Standard
