Specifications

• ENGINE

  add remove
  • Engine Type:
    Liquid-cooled single-cylinder
  • Bore And Stroke:
    76mm x 63mm
  • Induction:
    PGM-FI
  • Ignition:
    Full transistorized ignition
  • Compression Ratio:
    10.7:1
  • Valve Train:
    DOHC; 4 valves per cylinder
  • Displacement:
    286 cc
  • Final Drive:
    O-ring-sealed chain
  • Fuel Delivery:
    PGM-FI electronic fuel injection
  • Transmission:
    6-speed
• Chassis/ Suspension/ Brake

  add remove
  • Front Suspension:
    41 mm telescopic fork; 121 mm (4.8 in.) travel
  • Rear Suspension:
    Dual shocks with spring preload adjustment; 95 mm (3.7 in) travel
  • Front Brake:
    296 mm disc
  • Rear Brake:
    240 mm disc
  • Front Tire:
    130/90-16
  • Rear Tire:
    150/80-16
• Dimensions

  add remove
  • Rake:
    28°0'
  • Trail:
    110mm (4.3 inches)
  • Wheelbase:
    1,490 mm (58.7 in.)
  • Seat Height:
    690 mm (27.2 in.)
  • Curb Weight:
    167 kg (368 lb) including required fluids and full tank of gas—ready to ride
  • Fuel Capacity:
    11.2 litres
• Factory Warranty Information

  add remove
  • Warranty:
    12 months, unlimited mileage, freely transferable warranty; extended coverage available with Honda Plus
