Specifications

• ENGINE

  add remove
  • Engine Type:
    V Twin
  • Cylinders:
    2
  • Engine Stroke:
    4-Stroke
  • Cooling:
    Liquid
  • Valves:
    6
  • Valves Per Cylinder:
    3
  • Valve Configuration:
    SOHC
  • Bore (in):
    3.53
  • Stroke (in):
    4.11
  • Displacement (cc):
    1312
  • Carburetion Type:
    Carburetor
  • Number Of Carburetors:
    1
  • Compression Ratio:
    9.2:1
• TRANSMISSION

  add remove
  • Transmission Type:
    Manual
  • Number Of Speeds:
    5
  • Primary Drive (Rear Wheel):
    Shaft
  • Reverse:
    No
• TECHNICAL SPECIFICATIONS

  add remove
  • Wheelbase (in):
    65.5
  • Dry Weight (lbs):
    641
  • Fuel Capacity (gal):
    4.8
  • Fuel Capacity Reserve (gal):
    1
  • Engine Displacement to Weight (cc):
    2.05
• SUSPENSION

  add remove
  • Front Suspension Type:
    Telescopic Fork
  • Front Suspension Size (in):
    1.6
  • Front Travel (in):
    5.1
  • Front Adjustable Fork Pre-Load:
    No
  • Front Adjustable Rebound Damping:
    No
  • Rear Suspension Type:
    Twin Sided Swing Arm
  • Rear Travel (in):
    3.6
  • Rear Adjustable Shock / Spring Pre-Load:
    Yes
  • Rear Adjustable Rebound Damping:
    No
  • Number Rear Shock Absorbers:
    2
• WHEELS & TIRES

  add remove
  • Wheels Composition:
    Aluminum
  • Tube / Tubeless:
    Tubeless
  • Front Tire (Full Spec):
    110/90 R19
  • Rear Tire (Full Spec):
    170/80 R15
• BRAKES

  add remove
  • Front Brake Type:
    Disc
  • Front Brake Diameter (in):
    13.2
  • Rear Brake Type:
    Disc
  • Rear Brake Diameter (in):
    11.7
  • Anti-Lock Brakes:
    Not Available
