Specifications

• ENGINE

  add remove
  • Engine Type:
    Horizontal In-line
  • Cylinders:
    4
  • Engine Stroke:
    4-Stroke
  • Cooling:
    Liquid
  • Valves:
    16
  • Valves Per Cylinder:
    4
  • Valve Configuration:
    DOHC
  • Bore (in):
    2.99
  • Stroke (in):
    2.17
  • Displacement (cc):
    998
  • Compression Ratio:
    11.2:1
  • Carburetor:
    No
  • Carburetion Type:
    Fuel Injected
  • Turbocharged:
    No
  • Supercharged:
    No
  • Torque (Ft Lbs):
    101.1
  • Horsepower (bhp):
    197.1
• TRANSMISSION

  add remove
  • Transmission Type:
    Manual
  • Number Of Speeds:
    6
  • Primary Drive (Rear Wheel):
    Chain
  • Reverse:
    No
• TECHNICAL SPECIFICATIONS

  add remove
  • Length (in):
    82.1
  • Width (in):
    32
  • Height (in):
    44.5
  • Wheelbase (in):
    57.3
  • Ground Clearance (in):
    5.5
  • Wet Weight (lbs):
    527
  • Fuel Capacity (gal):
    5
• SUSPENSION

  add remove
  • Front Suspension Type:
    Inverted Fork
  • Front Travel (in):
    4.7
  • Front Adjustable Fork Pre-Load:
    Yes
  • Front Adjustable Rebound Damping:
    Yes
  • Front Central Suspension Strut:
    No
  • Rear Suspension Brand Name:
    UNI-TRAK®
  • Rear Suspension Type:
    Single Sided Swing Arm
  • Rear Travel (in):
    5.3
  • Rear Adjustable Shock / Spring Pre-Load:
    Yes
  • Rear Adjustable Rebound Damping:
    Yes
  • Number Rear Shock Absorbers:
    1
  • Rear Suspension Material:
    Aluminum
  • Steering Damper:
    Yes
  • Air Adjustable:
    No
  • Front Suspension Brand Name:
    Showa®
• WHEELS & TIRES

  add remove
  • Front Tire (Full Spec):
    Pirelli® Diablo™ Rosso III: 120/70 ZR17 M/C 58W
  • Rear Tire (Full Spec):
    Pirelli® Diablo™ Rosso III: 190/55 ZR17 M/C 75W
• BRAKES

  add remove
  • Front Brake Type:
    Dual Hydraulic Disc
  • Front Brake Diameter (in):
    12.6
  • Rear Brake Type:
    Hydraulic Disc
  • Rear Brake Diameter (in):
    10.2
  • Brake Brand Name:
    Brembo®
• SEATS

  add remove
  • Seat Type:
    Two-Piece
  • Seat Location:
    Driver and Passenger
  • Seat Material:
    Vinyl
  • Seat Height (in):
    32.7
  • Number Of Seats:
    1
