Specifications

• Engine & Transmission

  add remove
  • Engine Type:
    Liquid-cooled, 12 valve, DOHC, inline 3-cylinder
  • Capacity:
    888 cc
  • Bore:
    3.1 in
  • Stroke:
    2.4 in
  • Compression:
    11.27:1
  • Max Power:
    62.5 kW / 8500 rpm
  • Max Torque:
    60.5 ft-lb / 6500 rpm
  • System:
    Multipoint sequential electronic fuel injection
  • Exhaust:
    Stainless steel 3 into 1 header system, side mounted stainless steel silencer
  • Final Drive:
    O-ring chain
  • Clutch:
    Wet, multi-plate, slip
  • Gearbox:
    6 speed
• Chassis

  add remove
  • Frame:
    Tubular steel frame, bolt on sub frame
  • Swingarm:
    Twin-sided, cast aluminium
  • Front Wheel:
    Cast alloy, 19 x 2.5 in
  • Rear Wheel:
    Cast alloy, 17 x 4.25 in
  • Front Tyre:
    100/90-19
  • Rear Tyre:
    150/70R17
  • Front Suspension:
    Marzocchi 45mm upside down forks
  • Rear Suspension:
    Marzocchi rear suspension unit, manual preload adjustment
  • Front Brake:
    Twin 320mm floating discs, Brembo Stylema 4 piston Monobloc calipers. Radial front master cylinder, ABS
  • Rear Brake:
    Single 255mm disc. Brembo single piston sliding caliper, ABS
• Dimensions & Weights

  add remove
  • Width Handlebars:
    32.7 in
  • Height Without Mirror:
    1410-1460 mm
  • Seat Height:
    810-830 mm
  • Wheelbase:
    61.3 in
  • Rake:
    24.6 º
  • Trail:
    5.2 in
  • Tank Capacity:
    5.3 gal
  • Dry Weight:
    423 lbs
