Specifications

• Engine & Transmission

  add remove
  • Engine Type:
    Liquid-cooled, 12 valve, DOHC, in-line 3-cylinder
  • Capacity:
    888 cc
  • Bore:
    3.1 in
  • Stroke:
    2.4 in
  • Compression:
    13.0:1
  • Max Power:
    79.5 kW / 9500 rpm
  • Max Torque:
    66.4 ft-lb / 6850 rpm
  • System:
    Multipoint sequential electronic fuel injection with electronic throttle control
  • Exhaust:
    Stainless steel 3 into 1 header system, side mounted stainless steel silencer
  • Final Drive:
    O-ring chain
  • Clutch:
    Wet, multi-plate, slip and assist
  • Gearbox:
    6 speed
• Chassis

  add remove
  • Frame:
    Tubular steel trellis main frame. Fabricated, bolt-on aluminium rear subframe
  • Swingarm:
    Twin-sided, cast aluminium alloy
  • Front Wheel:
    Cast aluminium, 19 x 2.5 in
  • Rear Wheel:
    Cast aluminium, 17 x 4.25 in
  • Front Tyre:
    Metzeler TouranceTM Next, 100/90-19
  • Rear Tyre:
    Metzeler TouranceTM Next, 150/70R17
  • Front Suspension:
    Marzocchi 45mm upside down forks, manual rebound and compression damping adjustment, 180mm travel
  • Rear Suspension:
    Marzocchi rear suspension unit, manual preload and rebound damping adjustment, 170mm wheel travel
  • Front Brake:
    Twin 320mm floating discs, Brembo Stylema 4 piston Monobloc calipers. Radial front master cylinder, Optimised Cornering ABS
  • Rear Brake:
    Single 255mm disc. Single piston sliding caliper. Optimised cornering ABS
  • Instrument Display and Functions:
    Full-colour 7” TFT instrument pack with My Triumph Connectivity System
• Dimensions & Weights

  add remove
  • Width Handlebars:
    36.6 in
  • Height Without Mirror:
    1410 low screen position 1460 high screen position mm mm
  • Seat Height:
    Adjustable 820 - 840 mm
  • Wheelbase:
    61.3 in
  • Rake:
    24.6 º
  • Trail:
    4.0 in
  • Tank Capacity:
    5.3 gal
  • Wet Weight:
    219 kg
• Fuel Consumption

  add remove
  • Fuel Consumption:
    60.4 mpg (4.7 litres / 100 km)
  • CO₂ Figures:
    108 g/km EURO 5+ CO2 emissions and fuel consumption data are measured according to regulation 168/2013/EC. Figures for fuel consumption are derived from specific test conditions and are for comparative purposes only. They may not reflect real driving resu
• Features

  add remove
  • Lighting:
    All-LED Lighting with Daytime Running Light
• Technology

  add remove
  • Riding modes:
    x 4: Road, Rain, Sport and Off-Road
  • Instruments:
    Full-colour 7” TFT
  • ABS:
    Optimised Cornering ABS
  • Navigation:
    Yes
  • Bluetooth:
    Yes
