Specifications

• Engine & Transmission

  add remove
  • Engine Type:
    Liquid-cooled, 3 cylinders, 12 valves, DOHC
  • Capacity:
    660 cc
  • Bore:
    2.9 in
  • Stroke:
    2.0 in
  • Compression:
    12:1
  • Max Power:
    70 kW / 11250 rpm
  • Max Torque:
    50.2 ft-lb / 8250 rpm
  • System:
    Multipoint, sequential electronic fuel injection with electronic throttle control
  • Exhaust:
    Stainless steel 3 into 1 header system with low single sided stainless steel silencer
  • Final Drive:
    X-ring chain
  • Clutch:
    Wet, multi-plate, slip and assist
  • Gearbox:
    6 speed
• Chassis

  add remove
  • Frame:
    Tubular steel perimeter frame
  • Swingarm:
    Twin-sided, fabricated pressed steel
  • Front Tyre:
    120/70 R 17
  • Rear Tyre:
    180/55 R 17
  • Front Suspension:
    Showa 41 mm, upside-down separate function cartridge forks, 150 mm wheel travel
  • Rear Suspension:
    Showa monoshock RSU, with remote hydraulic preload adjustment, 150 mm wheel travel
  • Front Brake:
    Twin, 310 mm fixed discs, 2-piston sliding calipers, OCABS
  • Rear Brake:
    Single, 255 mm disc, single-piston sliding caliper, OCABS
  • Instrument Display and Functions:
    LCD multi-function instruments with integrated colour TFT screen
• Dimensions & Weights

  add remove
  • Width Handlebars:
    32.6 in
  • Height Without Mirror:
    54.9 in
  • Seat Height:
    32.9 in
  • Wheelbase:
    55.8 in
  • Rake:
    23.1 º
  • Trail:
    3.8 in
  • Tank Capacity:
    4.9 gal
  • Wet Weight:
    211 kg
• Fuel Consumption

  add remove
  • Fuel Consumption:
    57.6 mpg (4.9 l/100km)
