Specifications

• Engine & Transmission

  add remove
  • Engine Type:
    Liquid-cooled, 12-valve, DOHC, inline 3-cylinder
  • Capacity:
    888 cc
  • Bore:
    3.1 in
  • Stroke:
    2.4 in
  • Compression:
    11.27:1
  • Max Power:
    70 kW / 8750 rpm
  • Max Torque:
    64.2 ft-lb / 7250 rpm
  • System:
    Multi-point sequential electronic fuel injection
  • Exhaust:
    Stainless steel 3-into-1 header system, side mounted stainless steel silencer
  • Final Drive:
    O-ring chain
  • Clutch:
    Wet, multi-plate
  • Gearbox:
    6-speed
• Chassis

  add remove
  • Frame:
    Tubular steel frame, bolt-on subframe
  • Swingarm:
    Twin-sided, cast aluminum alloy
  • Front Wheel:
    Spoked Tubeless, 21 x 2.15 in
  • Rear Wheel:
    Spoked Tubeless, 17 x 4.25 in
  • Front Tyre:
    90/90-21
  • Rear Tyre:
    150/70R17
  • Front Suspension:
    Showa 45 mm upside down forks, manual preload, rebound damping and compression damping adjustment, 9.44 in (240 mm) travel.
  • Rear Suspension:
    Showa rear suspension unit, manual preload and rebound damping adjustment, 9.05 in (230 mm) wheel travel.
  • Front Brake:
    Twin 320 mm floating discs, Brembo Stylema 4-piston Monobloc calipers. Radial front master cylinder, Multi-mode ABS, Optimized Cornering ABS.
  • Rear Brake:
    Single 255 mm disc. Brembo single-piston sliding caliper, Multi-mode ABS, Optimized cornering ABS
• Dimensions & Weights

  add remove
  • Width Handlebars:
    36.8 in
  • Height Without Mirror:
    1452-1502 mm
  • Seat Height:
    850-870 mm
  • Wheelbase:
    61.1 in
  • Rake:
    24.4 º
  • Trail:
    5.7 in
  • Tank Capacity:
    5.3 gal
  • Dry Weight:
    443 lbs
• Fuel Consumption

  add remove
  • Fuel Consumption:
    5.2l/100 km (55.4 MPG)
  • CO₂ Figures:
    EURO 5 Standard: 119 g/km CO2 and fuel consumption are measured according to regulation 168/2013/EC. Figures on fuel consumption are derived from specific test conditions and are for comparative purposes only. They may not reflect real driving results.
