Specifications

• Engine & Transmission

  add remove
  • Engine Type:
    Liquid-cooled, 12-valve, DOHC, inline 3-cylinder
  • Capacity:
    888 cc
  • Bore:
    78mm mm
  • Stroke:
    61.9mm mm
  • Compression:
    11.27:1
  • System:
    Multi-point sequential electronic fuel injection
  • Exhaust:
    Stainless steel 3-into-1 header system, side mounted stainless steel silencer
  • Final Drive:
    O-ring chain
  • Clutch:
    Wet, multi-plate
  • Gearbox:
    6-speed
• Chassis

  add remove
  • Frame:
    Tubular steel frame, bolt-on subframe
  • Swingarm:
    Twin-sided, cast aluminum alloy
  • Front Wheel:
    Cast alloy, 19 x 2.5 in
  • Rear Wheel:
    Cast alloy, 17 x 4.25 in
  • Front Tyre:
    100/90-19
  • Rear Tyre:
    150/70R17
  • Front Suspension:
    Marzocchi 45 mm upside down forks, manual rebound and compression damping adjustment, 7.08 in (180 mm) travel.
  • Rear Suspension:
    Marzocchi rear suspension unit, electronically adjustable preload and rebound damping, 6.69 in (170 mm) wheel travel.
  • Front Brake:
    Twin 320 mm floating discs, Brembo Stylema 4-piston Monobloc calipers. Radial front master cylinder, Multi-mode ABS, Optimized Cornering ABS.
  • Rear Brake:
    Single 255 mm disc. Brembo single-piston sliding caliper, Multi-mode ABS, Optimized cornering ABS
• Dimensions & Weights

  add remove
  • Width Handlebars:
    36.6 in
  • Height Without Mirror:
    1410-1460 mm
  • Seat Height:
    810-830 mm
  • Wheelbase:
    1,556.0 in
  • Rake:
    24.6 º
  • Trail:
    5.2 in
  • Tank Capacity:
    5.3 gal
  • Dry Weight:
    437 lbs
