Specifications

• Engine & Transmission

  add remove
  • Engine Type:
    Liquid-cooled, 3 cylinders, 12 valves, DOHC
  • Capacity:
    660 cc
  • Bore:
    2.9 in
  • Stroke:
    2.0 in
  • Compression:
    11.95:1
  • Max Power:
    59.6 kW / 10250 rpm
  • Max Torque:
    47.2 ft-lb / 6250 rpm
  • System:
    Multipoint sequential electronic fuel injection with electronic throttle control
  • Exhaust:
    Stainless steel 3 into 1 header system with low single sided stainless steel silencer
  • Final Drive:
    X-ring chain
  • Clutch:
    Wet, multi-plate, slip
  • Gearbox:
    6 speed, Triumph Shift Assist
• Chassis

  add remove
  • Frame:
    Tubular steel perimeter frame
  • Swingarm:
    Twin-sided, fabricated pressed steel
  • Front Wheel:
    Cast aluminium alloy 5 spoke, 17 x 3.5 in
  • Rear Wheel:
    Cast aluminium alloy 5 spoke, 17 x 5.5 in
  • Front Tyre:
    120/70 R 17
  • Rear Tyre:
    180/55 R 17
  • Front Suspension:
    Showa 41mm upside down separate function cartridge forks, 150mm wheel travel
  • Rear Suspension:
    Showa monoshock RSU, with remote hydraulic preload adjustment, 150mm wheel travel
  • Front Brake:
    Twin Ø310mm discs, Nissin 2-piston sliding calipers, OCABS
  • Rear Brake:
    Single Ø255mm fixed disc, single piston sliding caliper, OCABS
  • Instrument Display and Functions:
    LCD Multifunction Instruments with integrated colour TFT screen
• Dimensions & Weights

  add remove
  • Width Handlebars:
    32.8 in
  • Height Without Mirror:
    1398 mm / 1315 mm (high / low screen position) mm
  • Seat Height:
    32.9 in
  • Wheelbase:
    55.8 in
  • Rake:
    23.1 º
  • Trail:
    3.8 in
  • Tank Capacity:
    4.5 gal
  • Wet Weight:
    207 kg
• Fuel Consumption

  add remove
  • Fuel Consumption:
    4.7 litres / 100 km (60.1 mpg)
  • CO₂ Figures:
    107 g/km EURO 5+. CO2 emissions and fuel consumption data are measured according to regulation 168/2013/EC. Figures for fuel consumption are derived from specific test conditions and are for comparative purposes only. They may not reflect real driving res
• Features

  add remove
  • Lighting:
    All-LED lighting with marker lights
  • Riding position:
    Adjustable windscreen
• Technology

  add remove
  • Riding modes:
    3 rider modes (Rain, Road, Sport)
  • Instruments:
    Multi-functional instruments with colour TFT
  • ABS:
    Optimised Cornering ABS
  • Cruise control:
    Yes
  • Shift assist:
    Quickshifter
